INFINITY3DP X3 PRO


Industrial-grade Desktop FDM 3D Printer|Heated Chamber.Dual Extruder Advanced Pro|ONE-CLIP【Professional】
Rapid x Quality x Massive
– Massive Build Volume 300 x 300 x 400 mm
– Nozzle Temperature 100-500°C
– Build Plate Temperature 0-210°C
– Chamber Temperature 0-150°C
– Layer Resolution 0.01mm (min.)
– Print Speed 300mm/sec (max.)
– Precise Printing with Standard Error ≤ 0.05mm
– Core XY Motion System
– Quick Release Platform|Carbon Fiber Print Bed
– Dual Extruder Advanced Pro|ONE-CLIP REMOVABLE DESIGN
– Dual Material Printing
– High TEMP. Engineering Material Supported (PEEK/PEEK+CF/PEEK+GF/PEKK/PPSU/PPS)
– Flexible ShoreA 95-50 Supported
– Solid Frame and Components
– Filament Run-out Sensor

FREE CALIBRATION (LEVELING AND QUALITY CHECK BEFORE SHIPPED OUT)
PLUG-AND-PLAY (100-110VAC or 200-240VAC, 1200W / Power Cord* 2)
DURABLE|with long service life
USER-FRIENDLY DESIGN|Ease of Use/Intuitive


Package Include:
1. 3D Printer – INFINITY3DP X3 PRO *1
2. Hotend  *2  <assembled on 3D printer>
3. Build Plate_Carbon Fiber Print Bed *1  <assembled on 3D printer>
4. USB *1
5. USB Cable *1
6. Cleaning Brush (Steel) *1
7. 3M Scotch® Glue Sticks *1
8. Power Cord *2
9. eSUN eBOX Lite *2
10. Scraper *1
11. Warranty Card *1

CATALOGUE

Category:

Description


PRINTER POSITIONINGIndustrial-grade Desktop FDM 3D Printer - Heated Chamber|Independent Dual Extruders【Professional】
PRINTER DIMENSIONW646 x D605 x H890 mm
BUILD VOLUME 300 x 300 x 400mm
NET WEIGHT67kg / 148 Ibs
SUPPORTED LANGUAGEEnglish|Chinese|Japanese
BODY STRUCTUREHeated Chamber
MOVING STRUCTURECore XY
NUMBER OF EXTRUDERS2
NOZZLE MODULEIndependent Dual Extruders|ONE-CLIP
EXTRUDER TYPEDirect
GEARBOX
NOZZLE DIAMETER0.5mm (default)|0.2, 0.4, 0.,6mm
BUILD PLATEQuick Release Platform|Borosilicate Glass
BUILD PLATE TEMP. (max.)210°C
CHAMBER TEMP. (max.)150°C
PRINT SPEED (max.)(Reliable 24/7)300mm/sec
TRAVEL SPEED (max.) 500mm/sec
LAYER RESOLUTION (min.)0.01mm (10µ)
FILAMENT DIAMETER1.75 mm
SUPPORTED FILAMENTPLA/ABS/Nylon/Carbon-Nylon/PETG/PC/Flexible/Glass Wool Filled PP/ASA
PEEK/PEEK+CF/PEEK+GF/PEKK/PPSU/PPS
FILAMENT BOX (eSUN)2
ASSIGNED FILAMENT
CALIBRATION (LEVELING AND QUALITY CHECK BEFORE SHIPPED OUT)
POWER REQUIREMENT (W.)(max.)1200W
VOLTAGE: 100-110VAC Or 200-240VACFactory-set
ELECTRONIC CONTROL32 bit MCU
CONNECTIVITYSD Card / USB Cable / USB Drive
EMERGENCY RECOVERYFilament Run-out Sensor
SOFTWARECura Infinity3DP Edition
SUPPORTED FILES .gcode / .stl
WARRANTY 1 Years
LCD7"/ 800 x 480pixels
STEPPER MOTOR DRIVER32 bit DSP Field-Oriented Controller
XYZ STEPPER MOTOR57mm 0.9°
XYZ-AXIS — THK LINEAR MOTION GUIDE
Z-AXIS — THK BALL SCREWS (ACCURACY GRADES C3)
Z POSITION — MECHANICAL OPTICAL TOUCH PROBE
ELECTRONIC CONTROL — IGUS CHAINFLEX® FLEXIBLE CABLES
NOTE● Standard
◎ Optional
— None

Additional information

Weight 162 kg
Input

110V, 220V

nozzle-diameter

0.2mm, 0.3mm, 0.4mm, 0.5mm, 0.6mm
